WH-2808E: 2-Way High Power Sub/Speaker Plate Amplifier
- Model No.
- WH-2808E
- Made in
- Taiwan
- Request for Quotation
Key Features
Feature:
- Flexible Inputs: Balanced analog and AES3 digital inputs.
- Integrated DSP: 16 multi-slope PEQ, XO, Limiter (power, attack, release).
- Dedicated PC GUI: Complete with LED indicator and intuitive PC control software allows full system control.
- Networked control: Preset management and full DSP parameter control via included Ethernet network controller software including amp status monitoring.
Tech Spec | WL-22028E | WH-2808E | |||
Output Power | 1000W RMS @ 8 Ω | Sub/600W RMS | |||
or 1500W RMS @ 4 Ω | L/R 150W RMS | ||||
Frequency Response | 8 Ω | 20 ~ 20KHz (±0.3dB) | |||
THD+N | < 1% @ 1kHz, Rated Power | ||||
Inputs | Sensitivity | 0.775Vrms | |||
Impedance | 10K Ω | ||||
Type | XLR3 x 1 | ||||
Digital Input |
| AES3 x 1 | |||
Outputs | Aux output | XLR3 x 1 | |||
AC Mains |
| 115/230V AC 50/60Hz | |||
DSP | 28-/56-bit, 50 MIPS HPF, LPF up to 36dB/oct. 8 multi-slope PEQs per channel Limiter | ||||
Power Amp | Class-D | ||||
Power Supply | SMPS | ||||
Control Interface | 10M Ethernet | ||||
Dimensions | WL-22028E | 240(W) x 395(H) x 81(D) (mm) | |||
WH-2808E | 160(W) x 375(H) x 70(D) (mm) | ||||
Weight | 3.3 Kg | 1.7 Kg | |||
